Tenders Description & Specification for Thyristorised Bridge Converter With Triggering Circuit Trainer
Thyristorised Bridge Converter With Triggering Circuit Trainer
To study the nature and generation of Control Signal for 3 phase Full-wave Controlled Rectifier.
To study the operation of a 3 phase Full-wave Controlled Bridge Rectifier with R load.To study the operation of a 3 phase Full-wave Controlled Bridge Rectifier with R-L load.
Features:
The board consists of the following built-in parts:
01. Three Phase line commuted fully-controlled thyristorised bridge converter.
02. Three pole power contractor with AC coil complete with Push-to-ON switch.
03. Four pole Miniature Circuit Breaker (MCB).
| Voltage (V) | 230 V |
| Condition | New |
| Frequency (Hz) | 50 Hz |
| Phase | Single Phase |
Ltekonline are the manufacturers of Thyristorised Bridge Converter With Triggering Circuit Trainer used to demonstrate engineering principles in Engineering Colleges, Engineering Schools andBasic Electrical Lab Equipmentfor Engineering Teaching Lab in Universities
