Radial and Ring Main Distribution System is specially designed to illustrate the working phenomenon of Distribution System configured as Radial and Ring Main Distribution System. Distribution System is the part of electric power system which connects the high voltage transmission networks to the low voltage consumer service points. Distribution Systems should be designed in a way that Voltage variation at consumer terminals must be maintained with in +-5%.
46609 provides complete learning content to develop Ring and Radial Distribution System manually. The Voltage regulation is studied by performing experiments & comparison. It includes inbuilt DC Variable Supply with adequate protections, precise digital meters are used along with separate sections for Radial and Ring Main Distribution System so that students can understand the significance of these systems in a proper sequence.

FeaturesDigital 3 nos. DC Voltmeter & 3 nos. DC Ammeter for accurate measurement
Separate connection for Radial & Ring Main System
Inbuilt DC Variable Supply
Isolation Transformer is provided for safe operation
Exclusive and attractive designed panel
Provided with inbuilt lamp load holders
Diagrammatic representation for the ease of
connections
Learning material CD
2 Year Warranty

Technical Specifications:
Mains Supply : 230V ± 10%V AC, 50Hz
Inbuilt Isolated DC Output Supply
Rated Voltage : 0 – 220V ± 10% (Variable)
额定电流:2
Transformer
Rating : 0.5kVA
Primary Voltage : 230V
Secondary Voltage : 150V
Variac
Input : 230V
Output : 0-270V
Current : 2A

Ltekonline are the manufacturers of Radial and Ring Main Distribution System Trainer used to demonstrate engineering principles in Engineering Colleges, Engineering Schools andBasic Electrical Lab Equipmentfor Engineering Teaching Lab in Universities
