X-Ray Fluorescence Spectrometer is the most advanced instrument for Precious Metals Analysis. The new generation (Silicon Drift Detector), beryllium window detector with digital multi-channel technology, is precisely able to analyze Precious Metals of all sizes and shapes.
Gold relies on weight, and instrument relies on precision. most obvious features are outstanding high precision, high resolution and HD camera. One-key intelligent operation simplifies the testing for gold, silver, platinum, palladium and other precious metals. The testing results fully conform to the GB/T 18043-2000 requirements.
Application Field
Gold Assay Lab
Jewelry Showroom / Factory
Precious Metal Metallurgical Plant
Quality Inspection Authorities
Gold Jewelry Hallmark Center
Pawnshop
Precious metal recovery
Humanized Design
更安全:x光集成的安全装置hutter interacts with interlock; housing is linked with high voltage enable terminal to prevent radiation.
Performance features
The most advanced detection technology - (Silicon Drift Detector), with ultra-high
resolution as low as 135eV.
large detecting area (25mm²); receiving more information in unit t Advantage: ime; better count rate and resolution; higher precious metal detection efficiency; better SNR and lower detection limit.
Digital multichannel technology
Advantage: effectively improve output efficiency, realize ultra-high counting rate, guarantee effective counting rate higher than 100K-CPS.
High power X-ray tube (tungsten target - beryllium window) and sophisticated collimation filter system
Advantage: higher excitation efficiency for precious metals, good for precious metal index detection.
Easy operation
Fine positioning system
Industrial ultra-high definition camera and 2D movable platform ensure accurate sample positioning Tiny sample detection - minimum 0.2mm
8 collimators and 4 filters provide free selection according to different sample
The smallest 0.2 mm collimator allows detecting tiny sample

Ltekonline are the manufacturers of Precious Metals Analyzer used to demonstrate engineering principles in Engineering Colleges, Engineering Schools andAlloy Testing Labfor Engineering Teaching Lab in Universities
