This training device includes modules such as solar power generation devices, photovoltaic panel power generation devices, inverters, and light-emitting controllers. Through related experiments, you can study the principles of solar and wind power generation, and cultivate students' corresponding knowledge and skills.

Features:

The unit circuit hanging box is fully configured and can be used in combination to complete the training content of various courses.

The relevant units can be flexibly added to or deleted from the experimental subjects to meet the needs of different users.

培训设备采用铝制列弗拉姆号e structure, and the power supply is integrated and installed.

The device has a good safety protection system.

Performance Parameters:

Overall capacity: <2KVA

Input power: single-phase AC120V ± 10% 60Hz

Working conditions:

Ambient temperature -10 ºC ~ + 40 ºC

Relative humidity < 85% (25 ºC)

Dimensions: Dimensions: Wind power device: 1210mm × 1210mm × 2440mm

Solar power generation device: 1500mm × 1500mm × 2750mm

raining platform size: 1610mm × 800mm × 1350mm

Weight: <280kg

Specific Characteristics:

Battery: 12 volts and 100 amps / hour;

Power: 600 Watt; Inverter input voltage: 12 volts direct current; Inverter output

Voltage: 230 Volt; Additional

Frequency: 60 Hertz; Includes: Horizontal axis wind generator, microprocessor regulator, wind protection, electronic torque control, mounting kit and photovoltaic module;

Features: The body of the generator must be in aluminum and have at least three blades, The alternator must be of Brush less type with permanent magnets, It must have an output voltage of 12 Vdc in solar panel and wind turbine, The mast of the support it must be in stainless steel, the energy produced must be approx. 30 kWh / month with 5.8 m / s (13 mph) wind speed, Minimum wind speed for activation should be 3.6 m / s (8 mph), Maximum wind speed should be 49.2 m / s (110mph ), It must supply a current clamp with a voltage range (AC / DC); 0 to 600 V and a current range (AC / DC); 0 to 200 A, An inverter that has a modified sinusoidal output waveform must be delivered, in addition to stopping due to low battery charge and protection against overloads, short circuits and over temperatures, The peak power corresponding to the maximum radiation must be 115 W, It must have a support mounted on wheels and with adjustable inclination, Include charge regulator for photovoltaic panels, with a maximum current of 20 A.
