Six dedicated long-life Peltier modules for temperature circulators, forming three groups of loops to independently control three temperature zones;
The engineering reinforced aluminum module treated by anodic oxidation technology not only retains the rapid thermal conductivity, but also has enough corrosion resistance;
Rapid rise and cooling rate, the fastest rise cooling rate 4.5 ℃ / s, save precious time experiment;
Independent control of the three-slot module, which can run three different PCR programs at the same time;
stepless adjustable hot cover with pressure protection, suitable for test tubes of different heights, avoiding thawing and evaporation;
friendly Windows interface, color touch screen control, high definition TFT display (8 inches, 800 x 600 pixels, 16 true colors), graphical menu navigation interface, extremely simple operation;
Built-in 11 standard program file templates, can quickly edit required files;
The program USES folder management, can be built directory;
Real-time display of program progress and remaining time, support intermediate programming of PCR instrument;
One-button rapid incubation to meet the needs of denaturation, enzyme digestion/enzyme ligation, ELISA and other experiments;
Large data storage capacity, which can store up to 10,000 files;
The hot cover temperature and working mode can be set to meet different experimental requirements;
Automatic power off protection. After the power is restored, the unfinished cycle will be executed automatically to ensure the safe operation of the whole process of amplification;
GLP experiment report, recording the operation information of each step of the program, and providing accurate data support for the analysis of experimental results;
User login management, three-level authority, password protection function to ensure data security;
USB interface, support U inventory/PCR data, or use USB mouse to control PCR instrument;
Support U disk and LAN update software;
One machine can control multiple PCR meters at the same time through network connection;
可选的微型无线蓝牙打印机record experimental program information easily and accurately;
Support the function of sending email reminders after the end of the experimental program.
Capacity: 3×(32×0.2ml )
Temperature Range: 0~100℃
Heating Rate: 5℃/s
Cooling Rate: 4℃/s
Uniformity: ≤±0.3℃
Accuracy: ≤±0.2℃
Display Resolution: 0.1℃
Temperature Control: BlockTube
Ramping Rate Adjustable: 0.1~5℃
Gradient Mode: Three slot can be set independently
Hot Lid Temperature: 30~110℃
Hot Lid Height Adjustable: Stepless Adjustable
Number of Programs: 10000 +(USB FLASH)
Max. No. of Step: 30
Max. No. of Cycle: 100
Time Increment/Decrement: 1 Sec ~ 600 Sec(support long PCR test)
Temp. Increment/Decrement: 0.1~10.0℃(support Touchdown test)
Pause Function: Yes
Auto Data Protection: Yes
Hold at 4℃: Forever
Print: Yes
LAN to computer: Yes
LCD: 8 inch,800×600 pels, TFT
Communication: USB2.0 , LAN
Power Supply: 85~264VAC , 47~63Hz , 600 W

Ltekonline are the manufacturers of Intelligent Three Slot Thermal Cycler with Independent Modules used to demonstrate engineering principles in Engineering Colleges, Engineering Schools andPCR Thermal Cyclerfor Engineering Teaching Lab in Universities
