This training device includes modules such as pumps, tanks, sensors, instruments, and PLC. Through relevant experiments, you can be familiar with process control principles and operating methods, and develop students' corresponding knowledge and skills.

Features:

Various sensors are equipped to complete the training content of various courses.

The device has a good safety protection system.

The training device adopts an aluminum profile frame structure, which is safe and convenient to use and not easy to be damaged.

Performance Parameters:

Input power: AC120V ± 10% 60Hz

Overall dimensions: 1600mm × 840mm × 1500mm

Overall capacity: <2KVA

Weight: <260kg

Working conditions:

Ambient temperature -10 ºC ~ + 40 ºC

Relative humidity < 85% (25 ºC)

Product composition

PLC

与现场总线接口,集成以太网,1 RS485, integrated port and 3 integrated RJ45 ports, with high-resolution display with integrated color, ability to display alarms and hardware faults, 32 digital inputs and 24 VDC, 32 digital Output 24 VDC, 8-bit analog input, voltage, current, RTD and thermal coupling with 16-bit resolution, integrated 16-bit resolution voltage and current analog with 4 outputs, integrated web server.

Control box

Equipped with power indicator, power output socket and safety power output terminal.

Single-phase power input, controlled by the leakage circuit breaker, equipped with an emergency stop control button. In an emergency, press the emergency stop button to cut off the power supply.
