The training sets include a variety of types of thyristor typical application circuit units, through the related experiments, can be familiar with thyristor electrical characteristics, to master the control principle and control mode, raises the student the corresponding knowledge and skills, suitable for higher vocational colleges, higher technical, secondary vocational school and technical school related professional teaching and skill training evaluation.

Features:

Unit circuit hanging box configuration are complete, combination use, complete variety of critiquing the training content.

It can be set for an experiment subjects related units hang flexible increase or decrease in the box, in order to meet different user requirements.

Training bench with aluminum column frame structure, the power supply built-in integrated installation, safe and convenient to use, is not easy to damage.

Training platform has a good safety protection system.

Power control panel

电源控制面板使用铝loy profile panel, enclosed body structure, and placed at the bottom of a connection as one.

Character Parameters:

Input power: three phase, five wire, 380V±10% 50Hz

Whole capacity: ＜2.0KVA

Work condition:

Environment temperature: -10℃～+40℃

Relative humidity: ＜85%(25℃)

Dimension:1600mm×800mm×1800mm

Weight: ＜100kg.
