This 8086 Microcomputer/single chip computer teaching experiment system is according to the requirements of scholars and many experiment in colleges and universities, combined with the electronic development and developed with development, application and experiment with the combination of high-tech equipment. The aim is to improve the development of electronic science and technology as soon as possible, improve the ability of the experimenter and solve the problem. The system has the following characteristics:

The system adopts modular structure design of open mode, through two sets of relatively independent bus maximum extension 2 application experiment board at the same time, the user can according to need to purchase the corresponding experiment board, reduces the cost, improve the flexibility, easy to upgrade.

The system of single machine running mode: the system in the absence of connected to the computer, automatically run in standalone mode, in this mode, the user can through the keyboard input to run the program (machine), and the operating instructions, at the same time the input information and the result of the operation on the LED digital tube display.

CPU can choose any type of CPU in 80C31, 8086, 80C196. The system is fully functional and covers most of the teaching experiment courses of microcomputer/MCU.

Equipped with two programmable devices: is occupied by the system. Another for user experimentation. Both devices can be programmed online via the JTAG interface. It's very convenient to use.

Complete system functions and strong expansibility. The provisions of this experiment system not only can completely meet the syllabus of basic interface chip experiments, its flexibility and extensibility, data bus, address bus and control bus) for the user can easily meet their curriculum design, graduation design used, etc

Flexible power supply interface: equipped with PC electromechanical outlet, it can be supplied by PC. It also has an external switching power supply, providing the required + 5V, plus or minus 12V, and its input is 220V ac.

在线系统的操作模式:装备ipped with system debugging software, system debugging software divided into DOS version and WINDOWS version, both of which are Chinese multi-window interface. Debugging program can open register window, memory window, variable window, anti-assembly window, waveform display window, etc., which can make the program debugging for users. This software integrates source program editing, compiling, linking, debugging and integration, each function is the drop-down menu, easy to learn. Hot keys are available for frequent use, which can improve the debugging efficiency of the program. 8051 debugging software not only supports assembly language, but also supports C language editing and debugging.
